Figure 2

(a) Schematic of the whole monochromator assembly, (b) photograph of the monochromator crystal cage (shown at nearly zero Bragg angle) and (c) schematic representation of the crystal arrangement (the second crystal of the DCM is not shown) where the purple stripes represent the incoming X-ray beams under different incidence angles/Bragg rotations.
