Case report of ¹⁸F–fluorodeoxyglucose positron emission tomography-computed tomography imaging of a patient with multiple endocrine gland metastases from small cell lung cancer

Introduction

Preferential metastatic sites of small cell lung cancer (SCLC) are the brain, liver, adrenal glands, bones, and marrow.1 The thyroid, breast, ovary, pancreas, stomach, intestine, and pituitary gland are relatively rare sites of metastasis.2-5 Synchronous multiple endocrine gland metastasis is rarely diagnosed with traditional imaging techniques such as ultrasound, computed tomography (CT), or magnetic resonance imaging. Herein, we report a rare case of simultaneous multiple endocrine gland metastasis revealed by ¹⁸F–FDG (¹⁸F-fluorodeoxy-glucose) positron emission tomography (PET)-CT.

Case Report

A 58-year-old Chinese woman underwent physical examination and CT at another hospital in July 2012, which revealed brain lesions highly suggestive of brain metastases with edema. She was a heavy smoker (50 packs/year for 30 years) and had a rural occupation, but no significant personal or familial medical history. She reported chronic dizziness, dyspnea on exertion, an occasional productive cough with clear phlegm, and a month of chronic back pain (starting in June 2012). She had not received any treatment for these symptoms.

A whole body baseline ¹⁸F–FDG PET-CT scan (Biograph 16HR, Siemens, Germany) was performed one week after brain CT demonstrated high FDG uptake in multiple endocrine glands (the body and brain were separately scanned with PET-CT because of resolution), including a 1.5 cm lesion in the right thyroid, the maximum standardized uptake value (SUVmax) was 6.2, and a 1.1 cm lesion in the right breast (SUV_max = 3.2), a 0.9 cm lesion in the pancreatic body (SUV_max = 5.1), a 2.9 cm mass in the right adrenal gland (SUV_max = 7.1), and a 2.8 cm mass in the left ovary (SUV_max = 7.2) were detected (Fig 1). Multiple suspicious brain metastatic lesions with edema were also observed, measuring 1–2 cm in diameter (SUV_max = 4.5). A high FDG uptake lesion (SUV_max = 7.1) was revealed by PET-CT in the inferior lobe of the right lung hilus beside the mediastinum. Transbronchial lung biopsy performed 10 days after PET-CT revealed SCLC (Fig 2). Six cycles of chemotherapy with cisplatin and irinotecan and whole brain radiotherapy (30 Gy) were administered. Seven months later, follow-up revealed greatly improved performance status (Fig 3). Further chemotherapy was suspended.

One year later, follow-up PET-CT revealed that all previous lesions in the right breast, pancreatic body, right adrenal gland, and left ovary had disappeared, and the right lung hilus lesion had reduced, suggesting a good response to chemotherapy. The brain nodules had also reduced (Fig 4). The lesion in the right thyroid gland appeared unchanged but was proven benign by ultrasound and fine needle aspiration. The patient died two years after the initial PET-CT examination.

The study protocol was approved by the ethics committee and was performed in accordance with the ethical standards of the Declaration of Helsinki. The participants provided written informed consent.

Discussion

A review of 31 articles published between 1989 and 2013 showed only 41 independent cases of primary lung carcinoma metastasis to the breast, including only 10 cases of SCLC. Breast metastasis from SCLC is often positive for CD56, CGA, Syn, NSE, and TTF-1, and negative for ER, PR, and HER2. Nevertheless, the breast lesion was not sampled in the present case and we cannot completely exclude the possibility of two synchronous primary cancers. PET-CT could be helpful to differentiate primary from metastatic lesions. In this case, the lung cancer was larger with a higher ¹⁸F-FDG uptake, as well as mediastinum lymph node metastasis, while the breast nodule was smaller with a lower FDG uptake.

Ovarian malignant lesions are generally primary carcinomas and less frequently metastases from extra-gynecological tumors.6 Ovarian metastasis from lung cancer represents only 2–4% of all ovarian metastatic lesions.6 Because of completely different treatment methods and prognosis, distinguishing between a primary and metastatic ovarian neoplasm is critical to administer the correct therapeutic strategy. Primary ovarian neoplasms often present as large complex masses accompanied by increased CA125 levels and metastatic signs to the greater omentum and peritoneum. Therefore, the characteristics of our case, including an oval mass with a smooth surface in the left ovary, unilateral ¹⁸F-FDG uptake, without intra-abdominal spread, suggested this lesion was likely a metastatic cancer, later confirmed by follow-up PET-CT results after chemotherapy.

Metastases to the pancreas are rare, found by autopsy in 3–12% of patients with advanced cancer.7 Lung cancer is the most frequent type of malignancy causing pancreatic metastasis (18–27%), followed by renal cell, breast, colorectal, and hepatobiliary tract cancers.7 SCLC is the most frequent cytological type of lung cancer that metastasizes to the pancreas (10%).8 Many patients with pancreatic metastases remain asymptomatic, as in the present case. Therefore, the disease is only diagnosed at an advanced stage. Early recognition of pancreatic metastasis in lung cancer patients is important because the patient then has a chance to receive the appropriate therapy and avoid serious complications, such as acute pancreatitis and obstructive jaundice.5 Recognition of pancreatic metastasis in patients with lung cancer is important for adequate patient management. The patient in this case had undergone abdomen CT scanning but the pancreatic lesion was not detected.

Fluorodeoxyglucose uptake information can guide biopsy. Despite the fact that the diagnosis of endocrine gland metastasis in this case was solely based on PET-CT, PET-CT was probably sufficient to accurately identify the metastases, based on the uptake of the lesions, as reported by a previous study.9

Because there were multiple lesions on PET-CT and because the primary SCLC had been identified, the suspected metastatic lesions were not all biopsied to confirm the diagnosis. Because of brain metastases, primary SCLC, and poor prognosis, additional diagnostic procedures were deemed unnecessary. CT scans and magnetic resonance imaging from the first hospital were not available to the authors.

In conclusion, this rare case of multiple endocrine gland metastases from SCLC suggests that whole body PET-CT is a useful tool to detect rare/asymptomatic metastases. We report this case to increase recognition of rare metastases from SCLC.

Disclosure

No authors report any conflict of interest.
