Barrett's Esophageal Adenocarcinoma with Neuroendocrine Cell Carcinoma Treated by Endoscopic Submucosal Dissection: A Case Report and Literature Review

1 Introduction

The incidence of Barrett's esophageal adenocarcinoma (BEA) has increased in recent years, especially in Western countries [1]. However, BEA with esophageal neuroendocrine cell carcinoma (NEC) is very rare. Endoscopic therapy, surgery, and chemotherapy are considered for treatment [2-4], although the disease progresses rapidly and has a poor prognosis with an overall survival of 14 months [5]. Here, we report a case of BEA with NEC that was resected en bloc through endoscopic submucosal dissection (ESD); notably, the patient has survived for 52 months without additional treatment.

2 Case Report

An 84-year-old man was referred to our hospital for unexpected weight loss (3 kg in 2 months). He had a history of diabetes, hypertension, and hyperlipidemia, smoked 20 cigarettes/day for 44 years, and had never consumed alcohol. He was taking oral hypoglycemic, antihypertensive, and lipid-regulating drugs but no antithrombotic drugs or proton pump inhibitors. Physical examination revealed no significant findings.

Upper gastrointestinal endoscopy under white light imaging revealed palisade vessels from the 12 to 1 o'clock direction at the gastroesophageal junction, leading to a diagnosis of short-segment Barrett's esophagus (BE). In addition, a 15-mm erythematous, flat elevated lesion with irregular margins was identified at the 3 o'clock position of the gastroesophageal junction (Figure 1a). Narrow-band imaging (NBI) identified the lesion as a brownish area (Figure 1b). NBI-magnifying endoscopy revealed a demarcation line, irregular microsurface pattern, and irregular microvascular pattern (Figure 1c,d), indicative of a neoplastic lesion. The tumor was extended by air delivery, and the depth of the lesion was considered equivalent to that of T1a. Biopsy results showed a well-differentiated tubular adenocarcinoma (tub1). Computed tomography (CT) revealed no evidence of metastatic lesions in the lymph nodes and distant organs. Based on these findings, a diagnosis of BEA (EG, Type 0-IIa, 15 mm, cT1a) was made, and ESD was performed using an IT-knife nano device (Olympus Medical Systems Co., Ltd, Tokyo, Japan). The procedure was completed without any complications.

Histopathological findings are shown (Figure 2a,b). There was a double layer of muscularis mucosae under the columnar epithelium, with BE in the background (Figure 2c,d). The lesion showed a well-differentiated to moderately differentiated tubular adenocarcinoma that grew in an irregular tubular structure from the mucosal epithelium to the proper mucosal layer and partially to the lamina muscularis mucosae, consistent with a raised area (Figure 3a–c). Furthermore, atypical cells with a high nuclear/cytoplasmic ratio proliferated densely spanning from the proper mucosal layer to the lamina muscularis mucosae (Figure 3b). These cells were positive for chromogranin A and synaptophysin (Figure 3d) and had a mitotic rate of 2–3 per 10 high-power fields (HPFs), and a Ki67 index of 20–30%, which led to the diagnosis of NEC. As we measured the area occupied by the NEC on histological sections and calculated its proportion relative to the total tumor area, which was found to be 20%, the final diagnosis was BEA (tub1> tub2) with focal neuroendocrine carcinoma, EG, Type 0–IIa, 13×9 mm, pT1a-DMM, ly0, v0, pHM0, pVM0. After the endoscopic treatment, the patient was discharged without significant adverse events. Considering the patient's advanced age and wishes, no additional surgery or adjuvant chemotherapy was performed. The risk of recurrence was fully explained to the patient. His progress was carefully monitored with an upper gastrointestinal endoscopy and a CT every 6 months. At the time of writing, the patient has survived for 52 months after ESD without metastatic recurrence.

3 Discussion

BE is characterized by a change from esophageal squamous epithelium to columnar epithelium with goblet cells and is recognized as a precancerous lesion of BEA [6]. BEA incidence is estimated to be 1.1% of all esophageal cancers [1]. However, its incidence has increased in recent years, mainly in Western countries. In contrast, NEC is a rare malignancy, accounting for only 0.3% of all esophageal cancers [1]. NEC onset is reported to be preceded by BEA, followed by clonal differentiation of a pluripotent cell into a neuroendocrine phenotype [7]. Kinoshita et al. reported that adenocarcinoma and NEC intermingle in the transition zone, with continuity observed in both lesions and that NEC may be a neuroendocrine differentiation of BEA [2]. Conversely, Spagnolo et al. proposed the diagnosis of collision carcinomas, in which two distinct histologic types are clearly distributed, and each can be clearly recognized at the border between tumors [8]; however, the exact mechanism remains unclear. In this case, the BEA and NEC were vertically aligned with a distinct vertical boundary but without horizontal contact, suggesting the possibility of a vertically arranged composite tumor.

As per WHO classification, neuroendocrine tumor (NET) is classified as NET G1 (well-differentiated, mitotic rate < HPFs and/or Ki67 index < 3%), NET G2 (well-differentiated, mitotic rate 2–20 HPFs and/or Ki67 index 3–20%), G3 (well-differentiated, mitotic rate > 20 HPFs and/or Ki67 index > 20%), NEC (Poorly differentiated, mitotic rate > 20 HPFs and/or Ki67 index > 20%), and mixed neuroendocrine-non-neuroendocrine neoplasm (MiNEN) [9]. MiNEN is characterized by NET and non-NET components, each occupying >30% of the tumor; the non-NET component is an invasive carcinoma, and NET and non-NET are composite tumors that migrate and mix [9]. Immunostaining images are also useful in NET diagnosis, and neuroendocrine markers such as chromogranin A and synaptophysin are expressed in 69.1% and 90.2% of NET, respectively [10]. In the present case, samples were positive for chromogranin A and synaptophysin, and had a Ki67 index of 20%–30%, but could not be categorized as having MiNEN because NEC accounted for only 20% of the total tumor.

Several studies have reported BEA with NEC components confined to the T1 layer (Table 1). Preoperative biopsies, including that of this case, predominantly reveal adenocarcinomas, making diagnosis challenging because of the tendency of NEC to develop subepithelial growth. NEC has a poor prognosis owing to its rapid progression and high risk of metastasis and recurrence; therefore, additional surgery and adjuvant chemotherapy [Cisplatin + Etoposide (VP-16) or Irinotecan (CPT-11)] may be considered even if the lesion is subjected to endoscopic resection [10]. Even if the lesions are localized and resectable at the time of surgery, multimodal treatment may improve the prognosis of esophageal NEC. For instance, Bibeau et al. reported a case of long-term survival after combined chemoradiotherapy and surgery for locally advanced BEA with NEC [4].

To the best of our knowledge, this is the first report of BEA with NEC where long-term survival of 52 months was achieved with ESD resection alone. Several factors may have contributed to the long-term survival of the patient with ESD alone, including the size of the lesion (13 mm), that only 20% of the total tumor was NEC, that the NEC was limited to lamina muscularis mucosae, and that en bloc resection was completed successfully. Nevertheless, this is not an established treatment protocol for such cases, and careful follow-up using upper gastrointestinal endoscopy and CT is necessary to monitor the risk of metastatic recurrence. Moreover, it is desirable to establish a treatment strategy by accumulating more cases in the future.

In conclusion, if pathology after endoscopic resection reveals BEA with NEC, careful follow-up is necessary after fully explaining to the patient the need for additional surgery or adjuvant chemotherapy, considering the risk of metastatic recurrence.

Consent

Informed consent was obtained from the patient for publication of this report and accompanying images.

Conflicts of Interest

The authors declare no conflicts of interest.
