Middle Cerebral Artery Flow Velocity Correlates With Common Carotid Artery Volume Flow Rate After CO2 Inhalation
Disya Ratanakorn MD
Division of Neurology, Department of Medicine, Faculty of Medicine Ramathibodi Hospital, Mahidol University, Bangkok, Thailand.
Division of Neurology, Department of Neurology, Wake Forest University School of Medicine, Winston-Salem, NC.
Search for more papers by this authorJason P. Greenberg MD
Division of Neurology, Department of Neurology, Wake Forest University School of Medicine, Winston-Salem, NC.
Search for more papers by this authorDana B. Meads RT-R, RVT
Diagnostic Ultrasound Laboratory, North Carolina Baptist Hospital, Winston-Salem, NC.
Search for more papers by this authorCorresponding Author
Charles H. Tegeler MD
Division of Neurology, Department of Neurology, Wake Forest University School of Medicine, Winston-Salem, NC.
Dr Tegeler, Department of Neurology, Wake Forest University School of Medicine, Medical Center Boulevard, Winston-Salem, NC 27157-1078. E-mail: [email protected].Search for more papers by this authorDisya Ratanakorn MD
Division of Neurology, Department of Medicine, Faculty of Medicine Ramathibodi Hospital, Mahidol University, Bangkok, Thailand.
Division of Neurology, Department of Neurology, Wake Forest University School of Medicine, Winston-Salem, NC.
Search for more papers by this authorJason P. Greenberg MD
Division of Neurology, Department of Neurology, Wake Forest University School of Medicine, Winston-Salem, NC.
Search for more papers by this authorDana B. Meads RT-R, RVT
Diagnostic Ultrasound Laboratory, North Carolina Baptist Hospital, Winston-Salem, NC.
Search for more papers by this authorCorresponding Author
Charles H. Tegeler MD
Division of Neurology, Department of Neurology, Wake Forest University School of Medicine, Winston-Salem, NC.
Dr Tegeler, Department of Neurology, Wake Forest University School of Medicine, Medical Center Boulevard, Winston-Salem, NC 27157-1078. E-mail: [email protected].Search for more papers by this authorABSTRACT
Cerebral vasoreactivity can be studied with transcranial Doppler (TCD) by monitoring CO2-induced middle cerebral artery (MCA) velocity changes. Expected MCA mean velocity (Vm) changes due to changes in end-expiratory CO2(EE-CO2) are established, but reactivity of common carotid artery (CCA) volume flow rate (VFR) has not been extensively reported. The authors assess the relationship between MCA Vm, CCA VFR, and EE-CO2. Ten normal individuals without cerebrovascular disease and with CCA diameters of more than 3.0 mm were studied. CCA VFR was obtained by Color Velocity Imaging Quantification and ipsilateral MCA Vm by standard TCD methods. Each side was studied before, during, and after inhalation of 5% CO2. EE-CO2, blood pressure, and pulse rate were monitored. Four women and 6 men with mean age of 36 years were included. Significant correlations between MCA Vm and EE-CO2, CCA VFR and EE-CO2, and MCA Vm and CCA VFR were found. MCA Vm and CCA VFR increased 5.2% and 4.3% per mm Hg increase in EE-CO2, respectively. MCA Vm increased 0.3 cm/s per ml/min increase in CCA VFR. In normal individuals, there is a direct correlation between MCA Vm, CCA VFR, and EE-CO2. Measurement of CCA VFR changes during CO2inhalation may be an alternative method to estimate cerebral vasoreactivity when the MCA velocity cannot be obtained because of inadequate acoustic temporal windows.
References
- 1 Ringelstein EB, Eyck SV, Mertens I. Evaluation of cerebral vasomotor reactivity by various vasodilating stimuli: comparison of CO2 to acetazolamide. J Cereb Blood Flow Metab 1992; 12: 162–168.
- 2 Mancini M, de Chiara S, Postiglione A, Ferrara LA. Transcranial Doppler evaluation of cerebrovascular reactivity to acetazolamide in normal subjects. Artery 1993; 20: 231–241.
- 3 Ringelstein EB, Sievers C, Ecker S, Schneider PA, Otis SM. Noninvasive assessment of CO2-induced cerebral vasomotor response in normal individuals and patients with internal carotid artery occlusions. Stroke 1988; 19: 963–969.
- 4 Widder B, Kleiser B, Krapf H. Course of cerebrovascular reactivity in patients with carotid artery occlusions. Stroke 1994; 25: 1963–1967.
- 5 Silvestrini M, Troisi E, Matteis M, Cupini LM, Caltagirone C. Transcranial Doppler assessment of cerebrovascular reactivity in symptomatic and asymptomatic severe carotid stenosis. Stroke 1996: 27; 1970–1973.
- 6 Russell D, Dybevold S, Kjartanson O, Nyberg-Hansen R, Rootwelt K, Wiberg J. Cerebral vasoreactivity and blood flow before and 3 months after carotid endarterectomy. Stroke 1990; 21: 1029–1032.
- 7 Sbarigia E, Speziale F, Giannoni MF, Colonna M, Panico MA, Fiorani P. Post-carotid endarterectomy hyperperfusion syndrome: preliminary observations for identifying at risk patients by transcranial Doppler sonography and the acetazolamide test. Eur J Vasc Surg 1993; 7: 252–256.
- 8 Hartl WH, Janssen I, Furst H. Effect of carotid endarterectomy on patterns of cerebrovascular reactivity in patients with unilateral carotid artery stenosis. Stroke 1994; 25: 1952–1957.
- 9 Vorstrup S, Brun B, Lassen NA. Evaluation of the cerebral vasoreactivity by the acetazolamide test before EC-IC bypass surgery in patients with occlusion of the internal carotid artery. Stroke 1986; 17: 1291–1298.
- 10 Karnik R, Valentin A, Ammerer HP, Donath P, Slany J. Evaluation of vasomotor reactivity by transcranial Doppler and acetazolamide test before and after extracranial-intracranial bypass in patients with internal carotid artery occlusion. Stroke 1992; 23: 812–817.
- 11 Klingelhofer J, Sander D. Doppler CO2 test as an indicator of cerebral vasoreactivity and prognosis in severe intracranial hemorrhages. Stroke 1992; 23: 962–966.
- 12 Steiger HJ, Ciessinna E, Seiler RW. Identification of posttraumatic ischemia and hyperperfusion by determination of the effect of induced arterial hypertension on carbon dioxide reactivity. Stroke 1996; 27: 2048–2051.
- 13 Dahl A, Lindegaard KF, Russell D, et al. A comparison of transcranial Doppler and cerebral blood flow studies to assess cerebral vasoreactivity. Stroke 1992; 23: 15–19.
- 14 Dahl A, Russell D, Nyberg-Hansen R, Rootwelt K, Bakke SJ. Cerebral vasoreactivity in unilateral carotid artery disease: a comparison of blood flow velocity and regional cerebral blood flow measurements. Stroke 1994; 25: 621–626.
- 15 Dahl A, Russell D, Nyberg-Hansen R, Rootwelt K, Mowinckel P. Simultaneous assessment of vasoreactivity using transcranial Doppler ultrasound and cerebral blood flow in healthy subjects. J Cereb Blood Flow Metab 1994; 14: 974–981.
- 16 Markwalder TM, Grolimund P, Seiler RW, Roth F, Aaslid R. Dependency of blood flow velocity in the middle cerebral artery on end-tidal carbon dioxide partial pressure-a transcranial ultrasound Doppler study. J Cereb Blood Flow Metab 1984; 4: 368–372.
- 17 Kirkham FJ, Padayachee TS, Parsons S, Seargeant LS, House FR, Gosling RG. Transcranial measurement of blood velocities in the basal cerebral arteries using pulsed Doppler ultrasound: velocity as an index of flow. Ultrasound Med Biol 1986; 12: 15–21.
- 18 Arnold BJ, von Reutern GM. Transcranial Doppler sonography: examination technique and normal reference values. Ultrasound Med Biol 1986; 12: 115–123.
- 19 Tegeler CH, Kremkau FW, Hitchings LP. Color velocity imaging: introduction to a new ultrasound technology. J Neuroimaging 1991; 1: 85–90.
- 20 Bonnefous O, Pesque P. Time domain formulation of pulse-Doppler ultrasound and blood velocity estimation by cross correlation. Ultrason Imaging 1986; 8: 73–85.
- 21 Harrington K, Deane C, Campbell S. Measurement of volume flow with time domain and M-mode imaging: in vitro and in vivo validation studies. J Ultrasound Med 1996; 15: 715–720.
- 22 Westra S, Levy DJ, Chaloupka JC, et al. Carotid artery volume flow: in vivo measurement with time-domain-processing US. Radiology 1997; 202: 725–729.
- 23 Oleson J, Paulson OB, Lassen NA. Regional cerebral blood flow in man determined by the initial slope of the clearance of intraarterially injected 133Xe. Stroke 1971; 2: 519–540.
- 24 Yonas H, Gur D, Latchaw RE, Wolfson, SD Jr. Xenon computed tomographic blood flow mapping. In: JH Wood, ed. Cerebral Blood Flow: Physiologic and Clinical Aspects. New York : McGraw-Hill; 1987: 220–245.
- 25 Wada T, Kodaira K, Fujishiro K, Okamura T. Correlation of common carotid flow volume measured by ultrasonic quantitative flow meter with pathological findings. Stroke 1991; 22: 319–323.
- 26 Juul R, Slordahl SA, Torp H, Angelsen BAJ, Brubakk AO. Flow estimation using ultrasound imaging (color M-mode) and computer postprocessing. J Cereb Blood Flow Metab 1991; 11: 879–882.
- 27 Schoning M, Walter J, Scheel P. Estimation of cerebral blood flow through color duplex sonography of the carotid and vertebral arteries in healthy adults. Stroke 1994; 25: 17–22.
- 28 Kindt GW, Youmans JR, Conway LW. The use of ultrasound to determine cerebral arterial reserve. J Neurosurg 1969; 31: 544–549.
- 29 Breslau PJ, Knox R, Fell G, Greene FM, Thiele BL, Strandness, DE Jr. Effect of carbon dioxide on flow patterns in normal extracranial arteries. J Surg Res 1982; 32: 97–103.
- 30 Bahr RR, Buss E, Eicke BM, Paulus W. Effects of acetazolamide and CO2 on the extracranial volume flow rate and intracranial blood flow velocity [abstract]. J Neuroimaging 1997; 7: 267.
- 31 Demolis P, Chalon S, Giudicelli JF. Acetazolamide-induced vasodilation in the carotid vascular bed in healthy volunteers. J Cardiovasc Pharmacol 1995; 26: 841–844.
- 32 Ratanakorn D, Tegeler CH, Greenberg JP. Risks for inadequate temporal windows in transcranial Doppler sonography [abstract]. Neurology 1997; 48: A156.
