Mechanical stability and technical outcomes of monolithic CAD/CAM fabricated abutment-crowns supported by titanium bases: An in vitro study
Corresponding Author
João Pitta
Division of Fixed Prosthodontics and Biomaterials, University Clinics for Dental Medicine, University of Geneva, Geneva, Switzerland
Correspondence
João Pitta, Division of Fixed Prosthodontics and Biomaterials, University Clinics for Dental Medicine, University of Geneva, 1 Rue Michel-Servet, 1211 Genève 4. Switzerland.
Email: [email protected]
Contribution: Conceptualization (equal), Formal analysis (equal), Funding acquisition (lead), Investigation (lead), Methodology (lead), Writing - original draft (lead)
Search for more papers by this authorJenni Hjerppe
Departments of Oral and Maxillofacial Diseases, Helsinki University Hospital (HUH), Helsinki, Finland
Department of Prosthodontics and Stomatognathic physiology, University of Turku, Turku, Finland
Contribution: Formal analysis (equal), Writing - original draft (lead)
Search for more papers by this authorFelix Burkhardt
Division of Fixed Prosthodontics and Biomaterials, University Clinics for Dental Medicine, University of Geneva, Geneva, Switzerland
Contribution: Data curation (equal), Investigation (equal), Methodology (equal), Writing - review & editing (supporting)
Search for more papers by this authorVincent Fehmer
Division of Fixed Prosthodontics and Biomaterials, University Clinics for Dental Medicine, University of Geneva, Geneva, Switzerland
Contribution: Conceptualization (equal), Methodology (equal), Writing - review & editing (supporting)
Search for more papers by this authorPhilippe Mojon
Division of Fixed Prosthodontics and Biomaterials, University Clinics for Dental Medicine, University of Geneva, Geneva, Switzerland
Contribution: Formal analysis (lead), Writing - review & editing (supporting)
Search for more papers by this authorIrena Sailer
Division of Fixed Prosthodontics and Biomaterials, University Clinics for Dental Medicine, University of Geneva, Geneva, Switzerland
Contribution: Conceptualization (lead), Funding acquisition (supporting), Supervision (lead), Writing - review & editing (lead)
Search for more papers by this authorCorresponding Author
João Pitta
Division of Fixed Prosthodontics and Biomaterials, University Clinics for Dental Medicine, University of Geneva, Geneva, Switzerland
Correspondence
João Pitta, Division of Fixed Prosthodontics and Biomaterials, University Clinics for Dental Medicine, University of Geneva, 1 Rue Michel-Servet, 1211 Genève 4. Switzerland.
Email: [email protected]
Contribution: Conceptualization (equal), Formal analysis (equal), Funding acquisition (lead), Investigation (lead), Methodology (lead), Writing - original draft (lead)
Search for more papers by this authorJenni Hjerppe
Departments of Oral and Maxillofacial Diseases, Helsinki University Hospital (HUH), Helsinki, Finland
Department of Prosthodontics and Stomatognathic physiology, University of Turku, Turku, Finland
Contribution: Formal analysis (equal), Writing - original draft (lead)
Search for more papers by this authorFelix Burkhardt
Division of Fixed Prosthodontics and Biomaterials, University Clinics for Dental Medicine, University of Geneva, Geneva, Switzerland
Contribution: Data curation (equal), Investigation (equal), Methodology (equal), Writing - review & editing (supporting)
Search for more papers by this authorVincent Fehmer
Division of Fixed Prosthodontics and Biomaterials, University Clinics for Dental Medicine, University of Geneva, Geneva, Switzerland
Contribution: Conceptualization (equal), Methodology (equal), Writing - review & editing (supporting)
Search for more papers by this authorPhilippe Mojon
Division of Fixed Prosthodontics and Biomaterials, University Clinics for Dental Medicine, University of Geneva, Geneva, Switzerland
Contribution: Formal analysis (lead), Writing - review & editing (supporting)
Search for more papers by this authorIrena Sailer
Division of Fixed Prosthodontics and Biomaterials, University Clinics for Dental Medicine, University of Geneva, Geneva, Switzerland
Contribution: Conceptualization (lead), Funding acquisition (supporting), Supervision (lead), Writing - review & editing (lead)
Search for more papers by this authorAbstract
Objectives
To evaluate mechanical stability (survival and complication rates) and bending moments of different all-ceramic monolithic restorations bonded to titanium bases (hybrid abutment-crowns) or to customized titanium abutments compared to porcelain-fused-to-metal crowns (PFM) after thermo-mechanical aging.
Material and Methods
Sixty conical connection implants (4.3 mm-diameter) were divided in five groups (n = 12): PFM using gold abutment (GAbut-PFM), lithium disilicate crown bonded to customized titanium abutment (TAbut+LDS), lithium disilicate abutment-crown bonded to titanium base (TiBase+LDS), zirconia abutment-crown bonded to titanium base (TiBase+ZR), polymer-infiltrated ceramic-network (PICN) abutment-crown bonded to titanium base (TiBase+PICN). Simultaneous thermocycling (5°–55°C) and chewing simulation (1,200,000-cycles, 49 N, 1.67 Hz) were applied. Catastrophic and non-catastrophic events were evaluated under light microscope, and survival and complication rates were calculated. Specimens that survived aging were loaded until failure and bending moments were calculated.
Results
Survival rates after aging were 100% (TAbut+LDS, TiBase+LDS), 91.7% (GA-PFM), 66.7% (TiBase+ZR) and 58.3% (TiBase+PICN) and differed among the groups (p = .006). Non-catastrophic events as screw loosening (GA-PFM) and loss of retention or micro-/macro-movement (TiBase groups) were observed. Complication rates varied among the groups (p < .001). TiBase+PICN had lower bending moment than all the other groups (p < .001).
Conclusions
Hybrid abutment-crowns made of lithium disilicate can be an alternative to PFM-based restorations, although concerns regarding the bonded interface between the titanium base and abutment-crown can be raised. PICN and zirconia may not be recommended due to its inferior mechanical and bonding outcomes, respectively. Titanium customized abutment with bonded lithium disilicate crown appears to be the most stable combination.
