Quantification of cross-relaxation in downfield ¹H MRS at 7 T in human calf muscle

Sophia Swago

orcid.org/0000-0001-8334-4746

Department of Bioengineering, School of Engineering and Applied Sciences, University of Pennsylvania, Philadelphia, Pennsylvania, USA

Search for more papers by this author

Mark A. Elliott,

Mark A. Elliott

Department of Radiology, Perelman School of Medicine, University of Pennsylvania, Philadelphia, Pennsylvania, USA

Search for more papers by this author

Ravi Prakash Reddy Nanga,

Ravi Prakash Reddy Nanga

orcid.org/0000-0002-3644-5656

Department of Radiology, Perelman School of Medicine, University of Pennsylvania, Philadelphia, Pennsylvania, USA

Search for more papers by this author

Neil E. Wilson,

Neil E. Wilson

Department of Radiology, Perelman School of Medicine, University of Pennsylvania, Philadelphia, Pennsylvania, USA

Search for more papers by this author

Abigail Cember,

Abigail Cember

Department of Radiology, Perelman School of Medicine, University of Pennsylvania, Philadelphia, Pennsylvania, USA

Search for more papers by this author

Ravinder Reddy,

Ravinder Reddy

Department of Radiology, Perelman School of Medicine, University of Pennsylvania, Philadelphia, Pennsylvania, USA

Search for more papers by this author

Walter R. Witschey,

Corresponding Author

Walter R. Witschey

[email protected]

orcid.org/0000-0003-1669-2120

Department of Radiology, Perelman School of Medicine, University of Pennsylvania, Philadelphia, Pennsylvania, USA

Correspondence

Walter Witschey, Department of Radiology, 3400 Civic Center Blvd., South Pavilion, Room 11-155, Perelman School of Medicine, University of Pennsylvania, Philadelphia, PA 19104, USA.

Email: [email protected]

Search for more papers by this author

Sophia Swago,

Sophia Swago

orcid.org/0000-0001-8334-4746

Department of Bioengineering, School of Engineering and Applied Sciences, University of Pennsylvania, Philadelphia, Pennsylvania, USA

Search for more papers by this author

Mark A. Elliott,

Mark A. Elliott

Department of Radiology, Perelman School of Medicine, University of Pennsylvania, Philadelphia, Pennsylvania, USA

Search for more papers by this author

Ravi Prakash Reddy Nanga,

Ravi Prakash Reddy Nanga

orcid.org/0000-0002-3644-5656

Department of Radiology, Perelman School of Medicine, University of Pennsylvania, Philadelphia, Pennsylvania, USA

Search for more papers by this author

Neil E. Wilson,

Neil E. Wilson

Department of Radiology, Perelman School of Medicine, University of Pennsylvania, Philadelphia, Pennsylvania, USA

Search for more papers by this author

Abigail Cember,

Abigail Cember

Department of Radiology, Perelman School of Medicine, University of Pennsylvania, Philadelphia, Pennsylvania, USA

Search for more papers by this author

Ravinder Reddy,

Ravinder Reddy

Department of Radiology, Perelman School of Medicine, University of Pennsylvania, Philadelphia, Pennsylvania, USA

Search for more papers by this author

Walter R. Witschey,

Corresponding Author

Walter R. Witschey

[email protected]

orcid.org/0000-0003-1669-2120

Department of Radiology, Perelman School of Medicine, University of Pennsylvania, Philadelphia, Pennsylvania, USA

Correspondence

Walter Witschey, Department of Radiology, 3400 Civic Center Blvd., South Pavilion, Room 11-155, Perelman School of Medicine, University of Pennsylvania, Philadelphia, PA 19104, USA.

Email: [email protected]

Search for more papers by this author

First published: 18 February 2023

https://doi.org/10.1002/mrm.29615

Citations: 2

Click here for author-reader discussions

Funding information: National Heart, Lung, and Blood Institute, Grant/Award Numbers: F31 HL158217, R01 HL137984; National Institute of Biomedical Imaging and Bioengineering, Grant/Award Number: P41 EB029460

Share a link

Email
Wechat
Bluesky

Abstract

Purpose

The purpose of this study was to characterize the ¹H downfield MR spectrum from 8.0 to 10.0 ppm of human skeletal muscle at 7 T and determine the T₁ and cross-relaxation rates of observed resonances.

Methods

We performed downfield MRS in the calf muscle of 7 healthy volunteers. Single-voxel downfield MRS was collected using alternately selective or broadband inversion-recovery sequences and spectrally selective 90° E-BURP RF pulse excitation centered at 9.0 ppm with bandwidth = 600 Hz (2.0 ppm). MRS was collected using TIs of 50–2500 ms. We modeled recovery of the longitudinal magnetization of three observable resonances using two models: (1) a three-parameter model accounting for the apparent T₁ recovery and (2) a Solomon model explicitly including cross-relaxation effects.

Results

Three resonances were observed in human calf muscle at 7 T at 8.0, 8.2, and 8.5 ppm. We found broadband (broad) and selective (sel) inversion recovery T₁ = mean ± SD (ms): T_{1-broad,8.0ppm} = 2108.2 ± 664.5, T_1-sel,8.0ppm = 753.6 ± 141.0 (p = 0.003); T_{1-broad,8.2ppm} = 2033.5 ± 338.4, T_1-sel,8.2ppm = 135.3 ± 35.3 (p < 0.0001); and T_{1-broad,8.5ppm} = 1395.4 ± 75.4, T_1-sel,8.5ppm = 107.1 ± 40.0 (p < 0.0001). Using the Solomon model, we found T₁ = mean ± SD (ms): T_1-8.0ppm = 1595.6 ± 491.1, T_1-8.2ppm = 1737.2 ± 963.7, and T_1-8.5ppm = 849.8 ± 282.0 (p = 0.04). Post hoc tests corrected for multiple comparisons showed no significant difference in T₁ between peaks. The cross-relaxation rate σ_AB = mean ± SD (Hz) of each peak was σ_AB,8.0ppm = 0.76 ± 0.20, σ_AB,8.2ppm = 5.31 ± 2.27, and σ_AB,8.5ppm = 7.90 ± 2.74 (p < 0.0001); post hoc t-tests revealed the cross-relaxation rate of the 8.0 ppm peak was significantly slower than the peaks at 8.2 ppm (p = 0.0018) and 8.5 ppm (p = 0.0005).

Conclusion

We found significant differences in effective T₁ and cross-relaxation rates of ¹H resonances between 8.0 and 8.5 ppm in the healthy human calf muscle at 7 T.

Supporting Information

Filename

Description

mrm29615-sup-0001-Supinfo.docxWord 2007 document , 2.2 MB

Figure S1. The ¹H downfield region in a single subject after frequency-selective excitation (E-BURP 90° pulse centered at 9.0 ppm with bandwidth (BW) = 2 ppm, voxels = 40 × 40 × 40 mm, TR/TE = 7 s/20 ms), without water suppression (left), and with VAPOR (variable pulse power and optimized relaxation delays) water suppression showing attenuated metabolite peaks (right)

Figure S2. Antisymmetric water sidebands are visible (solid arrows) in the ¹H spectrum of a water phantom (top row) and in vivo (bottom row) with frequency-selective excitation (E-BURP 90° pulse with BW = 2 ppm, voxels = 40 × 40 × 40 mm, TR/TE = 1 s/20 ms) centered at 4.7 ppm on water (left column). Sidebands are not visible in the same frequency locations (dashed arrows) when the same sequence is applied with excitation centered at 9.0 ppm (right column, zoomed × 140) in either the phantom (top row) or in vivo (bottom row)

Figure S3. Recovery of magnetization and three-parameter fits for all subjects (n = 7) using broadband and selective inversion-recovery (IR) data. Both selective and broadband data for each subject were normalized to the magnetization of the subject's last selective TI (2500 ms) for each resonance

Figure S4. Percent error between estimated T₁ and true T₁ in 1000 simulated selective IR data sets, plotted against selective inversion efficiency k (k = 0 indicating no inversion, k = 1 indicating perfect inversion). The maximum error across the three resonances is < 16%. The average percent error was 2.01 ± 1.56%, 1.79 ± 1.40%, and 2.12 ± 2.00% for the 8.0, 8.2, and 8.5 ppm peaks, respectively

Figure S5. Percent error between estimated cross-relaxation rate σ_AB and true σ_AB of 1000 simulated data sets plotted against selective (k_sel) and broadband (k_broad) inversion efficiencies (k = 0 indicating no inversion, k = 1 indicating perfect inversion). The maximum error across the three resonances is < 16%. The average percent error was 2.18 ± 1.68%, 2.23 ± 1.77%, and 2.45 ± 1.95% for the 8.0, 8.2, and 8.5 ppm peaks respectively

Table S1. Empirically determined constraints [min, max] for the component frequencies, line widths, and phases used to assign Hankel singular value decomposition (HSVD) components

Note: The 8.2-ppm and 8.5-ppm peaks were always assigned one component, and the 8.0-ppm component was assigned between one and three components.

Please note: The publisher is not responsible for the content or functionality of any supporting information supplied by the authors. Any queries (other than missing content) should be directed to the corresponding author for the article.

REFERENCES

1Kreis R, Ernst T, Ross BD. Development of the human brain: in vivo quantification of metabolite and water content with proton magnetic resonance spectroscopy. Magn Reson Med. 1993; 30: 424-437.
10.1002/mrm.1910300405
CAS PubMed Web of Science® Google Scholar
2Marjańska M, Auerbach EJ, Valabrègue R, Van de Moortele PF, Adriany G, Garwood M. Localized ¹H NMR spectroscopy in different regions of human brain in vivo at 7 T: T2 relaxation times and concentrations of cerebral metabolites. NMR Biomed. 2012; 25: 332-339.
10.1002/nbm.1754
CAS PubMed Web of Science® Google Scholar
3Pouwels PJ, Frahm J. Regional metabolite concentrations in human brain as determined by quantitative localized proton MRS. Magn Reson Med. 1998; 39: 53-60.
10.1002/mrm.1910390110
CAS PubMed Web of Science® Google Scholar
4Govindaraju V, Young K, Maudsley AA. Proton NMR chemical shifts and coupling constants for brain metabolites. NMR Biomed. 2000; 13: 129-153.
10.1002/1099-1492(200005)13:3<129::AID-NBM619>3.0.CO;2-V
CAS PubMed Web of Science® Google Scholar
5de Graaf RA, Behar KL. Detection of cerebral NAD(+) by in vivo (1)H NMR spectroscopy. NMR Biomed. 2014; 27: 802-809.
10.1002/nbm.3121
CAS PubMed Web of Science® Google Scholar
6Fichtner ND, Henning A, Zoelch N, Boesch C, Kreis R. Elucidation of the downfield spectrum of human brain at 7 T using multiple inversion recovery delays and echo times. Magn Reson Med. 2017; 78: 11-19.
10.1002/mrm.26343
CAS PubMed Web of Science® Google Scholar
7Henning A, Fuchs A, Boesch C, Boesiger P, Kreis R. Downfield spectra at ultrahigh field. In Proceedings of the 16th Annual Meeting of ISMRM, Toronto, Ontario, Canada, 2008. p. 777.
Google Scholar
8Dreher W, Leibfritz D. New method for the simultaneous detection of metabolites and water in localized in vivo ¹H nuclear magnetic resonance spectroscopy. Magn Reson Med. 2005; 54: 190-195.
10.1002/mrm.20549
CAS PubMed Web of Science® Google Scholar
9Bagga P, Hariharan H, Wilson NE, et al. Single-voxel ¹H MR spectroscopy of cerebral nicotinamide adenine dinucleotide (NAD+) in humans at 7T using a 32-channel volume coil. Magn Reson Med. 2020; 83: 806-814.
10.1002/mrm.27971
CAS PubMed Web of Science® Google Scholar
10de Graaf RA, De Feyter HM, Brown PB, Nixon TW, Rothman DL, Behar KL. Detection of cerebral NAD(+) in humans at 7 T. Magn Reson Med. 2017; 78: 828-835.
10.1002/mrm.26465
PubMed Web of Science® Google Scholar
11MacMillan EL, Chong DG, Dreher W, Henning A, Boesch C, Kreis R. Magnetization exchange with water and T1 relaxation of the downfield resonances in human brain spectra at 3.0 T. Magn Reson Med. 2011; 65: 1239-1246.
10.1002/mrm.22813
CAS PubMed Web of Science® Google Scholar
12MacMillan EL, Boesch C, Kreis R. Magnetization exchange observed in human skeletal muscle by non-water-suppressed proton magnetic resonance spectroscopy. Magn Reson Med. 2013; 70: 916-924.
10.1002/mrm.24537
CAS PubMed Web of Science® Google Scholar
13Shemesh N, Dumez JN, Frydman L. Longitudinal relaxation enhancement in ¹H NMR spectroscopy of tissue metabolites via spectrally selective excitation. Chemistry. 2013; 19: 13002-13008.
10.1002/chem.201300955
CAS PubMed Web of Science® Google Scholar
14Bendel P, Margalit R, Salomon Y. Optimized ¹H MRS and MRSI methods for the in vivo detection of boronophenylalanine. Magn Reson Med. 2005; 53: 1166-1171.
10.1002/mrm.20442
CAS PubMed Web of Science® Google Scholar
15Geen H, Freeman R. Band-selective radiofrequency pulses. J Magn Reson (1969). 1991; 93: 93-141.
10.1016/0022-2364(91)90034-Q
Web of Science® Google Scholar
16Tkáč I, Starčuk Z, Choi IY, Gruetter R. In vivo ¹H NMR spectroscopy of rat brain at 1 ms echo time. Magn Reson Med. 1999; 41: 649-656.
10.1002/(SICI)1522-2594(199904)41:4<649::AID-MRM2>3.0.CO;2-G
CAS PubMed Web of Science® Google Scholar
17Barkhuijsen H, De Beer R, Van Ormondt D. Improved algorithm for noniterative time-domain model fitting to exponentially damped magnetic resonance signals. J Magn Reson (1969). 1987; 73: 553-557.
10.1016/0022-2364(87)90023-0
CAS Web of Science® Google Scholar
18Pijnappel W, Van den Boogaart A, De Beer R, Van Ormondt D. SVD-based quantification of magnetic resonance signals. J Magn Reson (1969). 1992; 97: 122-134.
10.1016/0022-2364(92)90241-X
Web of Science® Google Scholar
19Grad J, Bryant RG. Nuclear magnetic cross-relaxation spectroscopy. J Magn Reson (1969). 1990; 90: 1-8.
10.1016/0022-2364(90)90361-C
CAS Web of Science® Google Scholar
20Solomon I. Relaxation processes in a system of two spins. Phys Rev. 1955; 99: 559-565.
10.1103/PhysRev.99.559
CAS Web of Science® Google Scholar
21Virtanen P, Gommers R, Oliphant TE, et al. SciPy 1.0: fundamental algorithms for scientific computing in Python. Nat Methods. 2020; 17: 261-272.
10.1038/s41592-019-0686-2
CAS PubMed Web of Science® Google Scholar
22Just Kukurová I, Valkovič L, Ukropec J, et al. Improved spectral resolution and high reliability of in vivo ¹H MRS at 7 T allow the characterization of the effect of acute exercise on carnosine in skeletal muscle. NMR Biomed. 2016; 29: 24-32.
10.1002/nbm.3447
CAS PubMed Web of Science® Google Scholar
23Kemp GJ, Meyerspeer M, Moser E. Absolute quantification of phosphorus metabolite concentrations in human muscle in vivo by 31P MRS: a quantitative review. NMR Biomed. 2007; 20: 555-565.
10.1002/nbm.1192
CAS PubMed Web of Science® Google Scholar
24Pan J, Hamm J, Rothman D, Shulman R. Intracellular pH in human skeletal muscle by ¹H NMR. Proc Natl Acad Sci. 1988; 85: 7836-7839.
10.1073/pnas.85.21.7836
CAS PubMed Web of Science® Google Scholar
25Yoshizaki K, Seo Y, Nishikawa H. High-resolution proton magnetic resonance spectra of muscle. Biochim Biophys Acta. 1981; 678: 283-291.
10.1016/0304-4165(81)90218-X
CAS PubMed Web of Science® Google Scholar
26Kingsley PB, Ogg RJ, Reddick WE, Steen RG. Correction of errors caused by imperfect inversion pulses in MR imaging measurement of T1 relaxation times. Magn Reson Imaging. 1998; 16: 1049-1055.
10.1016/S0730-725X(98)00112-X
CAS PubMed Web of Science® Google Scholar
27Damon BM, Hsu AC, Stark HJ, Dawson MJ. The carnosine C-2 proton's chemical shift reports intracellular pH in oxidative and glycolytic muscle fibers. Magn Reson Med. 2003; 49: 233-240.
10.1002/mrm.10384
CAS PubMed Web of Science® Google Scholar
28Boesch C, Kreis R. Dipolar coupling and ordering effects observed in magnetic resonance spectra of skeletal muscle. NMR Biomed. 2001; 14: 140-148.
10.1002/nbm.684
CAS PubMed Web of Science® Google Scholar
29Kreis R, Boesch C. Orientation dependence is the rule, not the exception in ¹H-MR spectra of skeletal muscle: the case of carnosine In Proceedings of the 31st Annual Meeting of ISMRM [Virtual], 2000.
Google Scholar
30Balchandani P, Spielman D. Fat suppression for ¹H MRSI at 7T using spectrally selective adiabatic inversion recovery. Magn Reson Med. 2008; 59: 980-988.
10.1002/mrm.21537
CAS PubMed Web of Science® Google Scholar
31Wang L, Salibi N, Wu Y, Schweitzer ME, Regatte RR. Relaxation times of skeletal muscle metabolites at 7T. J Magn Reson Imaging. 2009; 29: 1457-1464.
10.1002/jmri.21787
CAS PubMed Web of Science® Google Scholar
