An approach combining the integral equation method with a generalized image technique for modeling incabin radio wave propagation
Corresponding Author
Wei-Jiang Zhao
Department of Electronics and Photonics, Institute of High Performance Computing, Agency for Science Technology and Research (A*STAR), Singapore
Correspondence
Wei-Jiang Zhao, Department of Electronics and Photonics, Institute of High Performance Computing, Agency for Science Technology and Research (A*STAR), Singapore 138632.
Email: [email protected]
Search for more papers by this authorEn-Xiao Liu
Department of Electronics and Photonics, Institute of High Performance Computing, Agency for Science Technology and Research (A*STAR), Singapore
Search for more papers by this authorBinfang Wang
Department of Electronics and Photonics, Institute of High Performance Computing, Agency for Science Technology and Research (A*STAR), Singapore
Search for more papers by this authorSi-Ping Gao
NUSNNI-NanoCore and the Department of Electrical and Computer Engineering, National University of Singapore, Singapore
Search for more papers by this authorChing Eng Png
Department of Electronics and Photonics, Institute of High Performance Computing, Agency for Science Technology and Research (A*STAR), Singapore
Search for more papers by this authorCorresponding Author
Wei-Jiang Zhao
Department of Electronics and Photonics, Institute of High Performance Computing, Agency for Science Technology and Research (A*STAR), Singapore
Correspondence
Wei-Jiang Zhao, Department of Electronics and Photonics, Institute of High Performance Computing, Agency for Science Technology and Research (A*STAR), Singapore 138632.
Email: [email protected]
Search for more papers by this authorEn-Xiao Liu
Department of Electronics and Photonics, Institute of High Performance Computing, Agency for Science Technology and Research (A*STAR), Singapore
Search for more papers by this authorBinfang Wang
Department of Electronics and Photonics, Institute of High Performance Computing, Agency for Science Technology and Research (A*STAR), Singapore
Search for more papers by this authorSi-Ping Gao
NUSNNI-NanoCore and the Department of Electrical and Computer Engineering, National University of Singapore, Singapore
Search for more papers by this authorChing Eng Png
Department of Electronics and Photonics, Institute of High Performance Computing, Agency for Science Technology and Research (A*STAR), Singapore
Search for more papers by this authorAbstract
An approach that combines the integral equation (IE) method with a generalized image technique (GIT) is proposed for modeling radio wave propagation inside an electrically large and imperfectly conducting closed environment. The electric current distribution on a transmit antenna solved with a method of moment procedure is expressed as a weighted sum of basis functions. Each basis function with a small dimension is thought as a subtransmitter. The GIT is introduced to compute the single and multiple reflections by imperfectly conducting walls due to the radiation from these subtransmitters. The proposed approach can be applied to predict the radio wave propagation from a transmitter in the vicinity of an electrically large environment. Its validity is demonstrated through some numerical examples where full-wave results are available.
