Volume 4, Issue 2-4 pp. 2062-2067

Original Article

Full Access

The Elastic Buckling Coefficient of a Rectangular Longitudinally Profiled (LP) Steel Plate with All Edges Simply-supported

Dongdong Xu,

Dongdong Xu

Dept. of Civil Engineering, Tsinghua University, Haidian District, Beijing, China

Search for more papers by this author

Yuanqing Wang,

Corresponding Author

Yuanqing Wang

[email protected]

Dept. of Civil Engineering, Tsinghua University, Haidian District, Beijing, China

Correspondence: Dr. Yuanqing Wang, Tsinghua University, Dept. of Civil Engineering, Haidian district, Beijing, China, Email: [email protected]Search for more papers by this author

Huiyong Ban,

Huiyong Ban

Dept. of Civil Engineering, Tsinghua University, Haidian District, Beijing, China

Search for more papers by this author

Xiaoling Liu,

Xiaoling Liu

Dept. of Civil Engineering, Tsinghua University, Haidian District, Beijing, China

Search for more papers by this author

Ming Liu,

Ming Liu

Dept. of product Research & Development, Angang Steel Company Limited, Tiedong District, Anshan, China

Search for more papers by this author

Dongdong Xu,

Dongdong Xu

Dept. of Civil Engineering, Tsinghua University, Haidian District, Beijing, China

Search for more papers by this author

Yuanqing Wang,

Corresponding Author

Yuanqing Wang

[email protected]

Dept. of Civil Engineering, Tsinghua University, Haidian District, Beijing, China

Correspondence: Dr. Yuanqing Wang, Tsinghua University, Dept. of Civil Engineering, Haidian district, Beijing, China, Email: [email protected]Search for more papers by this author

Huiyong Ban,

Huiyong Ban

Dept. of Civil Engineering, Tsinghua University, Haidian District, Beijing, China

Search for more papers by this author

Xiaoling Liu,

Xiaoling Liu

Dept. of Civil Engineering, Tsinghua University, Haidian District, Beijing, China

Search for more papers by this author

Ming Liu,

Ming Liu

Dept. of product Research & Development, Angang Steel Company Limited, Tiedong District, Anshan, China

Search for more papers by this author

First published: 01 September 2021

https://doi.org/10.1002/cepa.1522

Share a link

Email
Wechat
Bluesky

Abstract

The longitudinally profiled (LP) steel plate is a steel plate that having a special longitudinal shape which is continuously changed in the rolling direction by a special rolling process. It has many advantages, such as reducing the weight of structure, decreasing the number of the weld seem and improving seismic performance, which has widely application in ships, bridges and other areas. It will have broad application in the field of bridges construction in China. However, the local stability of the LP plate is less investigated in recently years. In this paper, the energy method was used to study about elastic buckling coefficient of a rectangular LP steel plate with all edges simply supported. Based on the Galerkin and Rayleigh-Ritz method (GRM), the elastic buckling coefficient was obtained by transforming into a method that to solve the eigenvalues of the feature matrix. the result was verified by FEA method. And the curves of the elastic buckling coefficient with the relevant parameters such as aspect ratio and thickness change rate will be giving.

References

1Richter K, Schmackpfeffer H. Longitudinally profiled plate cut costs. Join Mater. 1(6) (1988): 270–273.
Google Scholar
2Falko S, Michel M. Current world-wide trends in the use of modern steel plates for bridge constructions. Steel Bridge, 070 (2004): 1–19.
Google Scholar
3Brozzetti J. Design development of steel-concrete composite bridge in France, Journal of constructional steel research, 55 (2000): 229–243.
10.1016/S0143-974X(99)00087-5
Web of Science® Google Scholar
4Fukumoto Y, Takaku T, et al. Innovative Use of Profiled Steel Plates for Seismic Structural Performance. Advances in Structural Engineering, 8 (3) (2005): 247–257.
10.1260/1369433054349051
Web of Science® Google Scholar
5Tobias Lehnert. Special Heavy Plates and Steel Solutions for Bridge Building. Materials Science and Engineering, 236 (2017) 012059: 1–7.
Google Scholar
6Yuanqing Wang, Xiaoling Liu, et al. Deformation behavior at SLS of welded I-section steel beams with longitudinally profiled flanges. Journal of Constructional Steel Research, 146 (2018): 122–134.
10.1016/j.jcsr.2018.03.033
Web of Science® Google Scholar
7Olsson, R. G., Beitrag zur Knickung der Rechteckplatte von quadratisch veränderlicher Steifigkeit.Ing. Arch., 10 (3) (1939): 175–181.
Google Scholar
8Pines S, Gerard G. Instability analysis and design of an efficiently tapered plate under compressive loading. Aeronautical Sci., 14(10) (1947): 594–599.
10.2514/8.1461
Google Scholar
9Pope G. The Buckling of plates tapered in thickness. Reports and Memoranda, 1961, 3309: 1–16.
Google Scholar
10Harutoshi K, Keiichiro S. Buckling of rectangular plates with tapered thickness. Journal of Structural Engineering, 116(5) (1990): 1278–1289.
10.1061/(ASCE)0733-9445(1990)116:5(1278)
Web of Science® Google Scholar
11Nerantzaki MS, Katsikadelis JT. Buckling of plates with variable thickness—an analog equation solution. Engineering Analysis with Boundary Elements, 18 (1996): 149–154.
10.1016/S0955-7997(96)00045-8
Web of Science® Google Scholar
12Eisenberger M, Alexandrov A. Buckling loads of variable thickness thin isotropic plates. Thin-Walled Structures, 41 (2003): 871–889.
10.1016/S0263-8231(03)00027-2
Web of Science® Google Scholar
13Wittrick WH, Ellen CH. Buckling of tapered rectangular plates in compression. The Aeronautical Quarterly, 13(4) (1962): 308–326.
10.1017/S0001925900002547
Google Scholar
14Timoshenko, S.P., Gere, J.M. Theory of elastic stability, 2nd, Ed. McGraw-Hill, 1961, 180.
Google Scholar
