The radial artery (RA) is recommended as the vascular access of choice in patients undergoing coronary angiography and intervention. The procedural and clinical performance of dual- versus single-catheter strategy in patients undergoing transradial coronary angiography remains a matter of debate.

Methods

This is a study-level meta-analysis of randomized trials. The primary outcome was procedure time. The main secondary outcome was fluoroscopy time. Other outcomes of interest were contrast volume, crossover to other catheter strategy and RA spasm.

Results

A total of 2,062 patients (978 randomly assigned to dual-catheter and 1,084 to single-catheter strategy) included in seven trials were available for the quantitative synthesis. A dual-catheter strategy was associated with procedure time (standardized mean difference [95% confidence intervals (CI)], 0.55 [−0.69, 1.78]; p = .32), fluoroscopy time (−0.36 [−2.39, 1.67]; p = .68) and contrast volume (−0.93 [−3.79, 1.94]; p = .44) comparable to a single-catheter strategy. The risk for crossover was lower (risk ratio [95% CI], 0.14 [0.03, 0.70]; p = .025) while the risk for RA spasm was higher (1.81 [1.54, 2.12]; p < .001) among patients assigned to dual- versus single-catheter strategy.

Conclusions

This meta-analysis provides evidence for a comparable procedural performance of either dual- or single-catheter strategy for transradial coronary angiography. The fewer crossovers with dual-catheter strategy occur at the expense of more frequent radial artery spasm.

CONFLICT OF INTEREST

The authors declare no potential conflict of interest.

Supporting Information

Filename	Description
ccd28458-sup-0001-FigS1.tiffTIFF image, 2.3 MB	Figure S1 PRISMA flow chart for the trial selection process. PRISMA, preferred reporting items for systematic reviews and meta-analyses
ccd28458-sup-0002-FigS2.zipapplication/x-zip-compressed, 168.1 KB	Figure S2 Forest plots for secondary outcomes with dual- versus single-catheter strategy for transradial coronary angiography. Standardized mean difference for contrast volume (Panel A) and risk ratio for crossover (Panel B) and radial artery spasm (Panel C) with dual- versus single-catheter strategy for transradial coronary angiography. The diamonds indicate the point estimate and the left and the right ends of the lines the 95% confidence intervals.
ccd28458-sup-0003-FigS3.zipapplication/x-zip-compressed, 60.7 KB	Figure S3 Contour enhanced funnel plot for primary and main secondary outcomes with dual- versus single-catheter strategy for transradial coronary angiography. Contours are plotted for a range of significance levels defined by p-values of .01, .05, and .1. The publication bias for procedure (Panel A) and fluoroscopy time (Panel B) is evaluated by visual inspection and by a linear regression test of funnel ploy asymmetry (p = .67 and .15, respectively).
ccd28458-sup-0004-FigS4.zipapplication/x-zip-compressed, 94.3 KB	Figure S4 Influence analysis for primary and main secondary outcomes with dual- versus single-catheter strategy for transradial coronary angiography. Random-effects estimates for procedure (Panel A) and fluoroscopy time (Panel B) are computed omitting one study at time.
ccd28458-sup-0005-Tables.docxWord 2007 document , 40.7 KB	Table S1 PRISMA checklist. Table S2. Main characteristics and definitions of outcomes according to protocols across trials included in the study. Table S3. Assessment of risk of bias of trials included in the study. Table S4. Subgroup analysis for all outcomes.

Please note: The publisher is not responsible for the content or functionality of any supporting information supplied by the authors. Any queries (other than missing content) should be directed to the corresponding author for the article.

REFERENCES

1Neumann FJ, Sousa-Uva M, Ahlsson A, et al. ESC/EACTS guidelines on myocardial revascularization. Eur Heart J. 2019; 40(2): 87-165.
10.1093/eurheartj/ehy394
PubMed Web of Science® Google Scholar
2Bertrand OF, Rao SV, Pancholy S, et al. Transradial approach for coronary angiography and interventions: results of the first international transradial practice survey. JACC Cardiovasc Interv. 2010; 3(10): 1022-1031.
10.1016/j.jcin.2010.07.013
PubMed Web of Science® Google Scholar
3Shroff AR, Fernandez C, Vidovich MI, et al. Contemporary transradial access practices: results of the second international survey. Catheter Cardiovasc Interv. 2019; 93(7): 1276-1287.
10.1002/ccd.27989
PubMed Web of Science® Google Scholar
4Hahalis G, Aznaouridis K, Tsigkas G, et al. Radial artery and ulnar artery occlusions following coronary procedures and the impact of anticoagulation: ARTEMIS (radial and ulnar ARTEry occlusion meta-AnalysIS) systematic review and meta-analysis. J Am Heart Assoc. 2017; 6(8):e005430.
10.1161/JAHA.116.005430
PubMed Web of Science® Google Scholar
5Kim SM, Kim DK, Kim DI, Kim DS, Joo SJ, Lee JW. Novel diagnostic catheter specifically designed for both coronary arteries via the right transradial approach. A prospective, randomized trial of Tiger II vs. Judkins catheters. Int J Cardiovasc Imaging. 2006; 22(3–4): 295-303.
10.1007/s10554-005-9029-8
PubMed Web of Science® Google Scholar
6Mason PJ, Shah B, Tamis-Holland JE, et al. An update on radial artery access and best practices for transradial coronary angiography and intervention in acute coronary syndrome: a scientific statement from the American Heart Association. Circ Cardiovasc Interv. 2018; 11(9):e000035.
10.1161/HCV.0000000000000035
PubMed Web of Science® Google Scholar
7Xanthopoulou I, Stavrou K, Davlouros P, et al. Randomised comparison of JUDkins vs. tiGEr catheter in coronary angiography via the right radial artery: the JUDGE study. EuroIntervention. 2018; 13(16): 1950-1958.
10.4244/EIJ-D-17-00699
PubMed Web of Science® Google Scholar
8Schneider VS, Lubking L, Stahli BE, et al. Performance of one-compared with two-catheter concepts in transradial coronary angiography (from the randomized use of different diagnostic catheters-radial-trial). Am J Cardiol. 2018; 122(10): 1647-1651.
10.1016/j.amjcard.2018.07.039
PubMed Web of Science® Google Scholar
9Higgins JP, Altman DG, Gotzsche PC, et al. The Cochrane collaboration's tool for assessing risk of bias in randomised trials. BMJ. 2011; 343: d5928.
10.1136/bmj.d5928
PubMed Web of Science® Google Scholar
10Jadad AR, Moore RA, Carroll D, et al. Assessing the quality of reports of randomized clinical trials: is blinding necessary? Control Clin Trials. 1996; 17(1): 1-12.
10.1016/0197-2456(95)00134-4
CAS PubMed Google Scholar
11Higgins JP, Thompson SG, Deeks JJ, Altman DG. Measuring inconsistency in meta-analyses. BMJ. 2003; 327(7414): 557-560.
10.1136/bmj.327.7414.557
PubMed Google Scholar
12IntHout J, Ioannidis JP, Rovers MM, Goeman JJ. Plea for routinely presenting prediction intervals in meta-analysis. BMJ Open. 2016; 6(7):e010247.
10.1136/bmjopen-2015-010247
PubMed Web of Science® Google Scholar
13Moher D, Liberati A, Tetzlaff J, Altman DG. Preferred reporting items for systematic reviews and meta-analyses: the PRISMA statement. Ann Intern Med. 2009; 151(4): 264-269. W64.
10.7326/0003-4819-151-4-200908180-00135
PubMed Web of Science® Google Scholar
14Chen O, Goel S, Acholonu M, et al. Comparison of standard catheters versus radial artery-specific catheter in patients who underwent coronary angiography through transradial access. Am J Cardiol. 2016; 118(3): 357-361.
10.1016/j.amjcard.2016.05.010
PubMed Web of Science® Google Scholar
15Erden I, Golcuk E, Bozyel S, et al. Effectiveness of handmade "Jacky-like catheter" as a single multipurpose catheter in transradial coronary angiography: a randomized comparison with conventional two-catheter strategy. J Interv Cardiol. 2017; 30(1): 24-32.
10.1111/joic.12350
PubMed Web of Science® Google Scholar
16Turan B, Erkol A, Mutlu A, Dasli T, Erden I. Effectiveness of left Judkins catheter as a single multipurpose catheter in transradial coronary angiography from right radial artery: a randomized comparison with conventional two-catheter strategy. J Interv Cardiol. 2016; 29(3): 257-264.
10.1111/joic.12286
PubMed Web of Science® Google Scholar
17Tarighatnia A, Pourafkari L, Farajollahi A, Mohammadalian AH, Ghojazadeh M, Nader ND. Operator radiation exposure during transradial coronary angiography: effect of single vs. double catheters. Herz. 2018; 43(6): 535-542.
10.1007/s00059-017-4595-9
CAS PubMed Web of Science® Google Scholar
18Balaban Y. Effectiveness of a handmade "new carotid catheter" in transradial carotid angiography: a comparison with conventional multipurpose catheters. J Interv Cardiol. 2018; 31(1): 94-105.
10.1111/joic.12454
PubMed Web of Science® Google Scholar
19Langer C, Riehle J, Wuttig H, et al. Efficacy of a one-catheter concept for transradial coronary angiography. PLoS One. 2018; 13(1):e0189899.
10.1371/journal.pone.0189899
PubMed Web of Science® Google Scholar
20Plourde G, Abdelaal E, MacHaalany J, et al. Comparison of radiation exposure during transradial diagnostic coronary angiography with single- or multi-catheters approach. Catheter Cardiovasc Interv. 2017; 90(2): 243-248.
10.1002/ccd.26851
PubMed Web of Science® Google Scholar
21Langer C, Riehle J, Frey N, Wiemer M. Catheter stability in transradial coronary angiography: the one-catheter-concept and the impact of performance level in 1,419 patients. Int J Cardiol. 2015; 187: 680-682.
10.1016/j.ijcard.2015.03.322
PubMed Web of Science® Google Scholar
22Goldsmit A, Kiemeneij F, Gilchrist IC, et al. Radial artery spasm associated with transradial cardiovascular procedures: results from the RAS registry. Catheter Cardiovasc Interv. 2014; 83(1): E32-E36.
10.1002/ccd.25082
CAS PubMed Web of Science® Google Scholar
